LIB Temperature Test Chambers are available in a variety of sizes and configurations, including optional humidity capabilities. This temperature chambers including standard and customized models with a temperature range of -20, -40, -60 °C, or -86°C to +150 °C for temperature tests.Extended choice of options fitted to your testing. You can select your chamber from the door, refrigeration system, controller, language and so much more.
The temperature test chambers are designed to comply with a wide range of international testing standards, including UL 2580, UL 2271, UL 1642, UL 1973, UL 2054, IEC 62660-2, IEC 60068-2-30, IEC 61960, IEC 62133, SAE J2929, SAE J2464, SAE J2334, VW 80000, and IEC 61215, as well as IEC 62717 for luminaire material testing. This broad standards coverage makes the chambers suitable for battery, photovoltaic, automotive, lighting, and electronic component validation.
TH-100/ TH-225/TH-500/TH-800/TH-1000
LIB Industry
| Quantity: | |
|---|---|
Ranging size from 50L, 100L to 1500L standard models with quick shipping, this can support customer to use timely. And can supply customized chambers according to special request, such as size, performance and configurations. Temperature change rate of 1K/min,2K/min, 5K/min, can meet requirement for your test applications.
Advantages of the Temperature Test Chamber
1. High-Efficiency Operation: The temperature test chamber features an intuitive PID touchscreen controller, allowing users to create complex test profiles with multiple programmable steps. Ethernet and USB interfaces support real-time monitoring, data logging, and easy report generation, making test management faster and more streamlined. Its quiet operation ensures minimal disturbance in laboratories and research facilities.
2. Durable and Safe Construction: Built for long-term performance, the chamber interior is made of corrosion-resistant SUS304 stainless steel, capable of withstanding high temperatures and humidity. The robust 4 mm A3 steel exterior with protective coating guarantees industrial-grade durability. Integrated safety mechanisms, including over-temperature protection, grounding monitoring, and leakage prevention, safeguard both operators and equipment.
3. Precise and Stable Testing: Equipped with PT100 Class A sensors and advanced control algorithms, the chamber maintains temperature accuracy within ±0.5 °C. Uniform airflow and high-resolution monitoring ensure consistent conditions throughout the test space, providing reliable, repeatable results for materials, electronics, and automotive components.
4. Rapid and Flexible Temperature Cycling: The chamber supports fast heating and cooling rates, with customizable ramp speeds up to 20 °C/min, enabling efficient simulation of extreme temperature changes. Preloaded test programs reduce setup time and enhance throughput, allowing laboratories to complete extensive testing in less time.
5. User-Friendly and Low-Maintenance Design: Designed for convenience and longevity, the chamber operates quietly and maintains stable internal conditions. Features such as easy-to-clean stainless steel interiors, corrosion protection, and efficient defrosting systems simplify maintenance, extend equipment life, and ensure a safe and controlled testing environment.
Technical Parameters
| Model | T-100 | T-225 | T-500 | T-800 | T-1000 |
| Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 |
| Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1300*1540*2120 | 1500*1540*2140 |
| Interior Volume | 100L | 225L | 500L | 800L | 1000L |
| Heat load | 1000W | ||||
| Temperature Range | A : -20℃ ～ +150 ℃ | ||||
| B : -40℃ ～ +150 ℃ | |||||
| C: -70℃ ～ +150 ℃ | |||||
| Temperature Fluctuation | ± 0.5 ℃ | ||||
| Temperature Deviation | ± 2.0 ℃ | ||||
| Cooling Rate | 1 ℃ / min | ||||
| Heating Rate | 3 ℃ / min | ||||
| Cooling system | Mechanical compression refrigeration system | ||||
| Refrigerating unit | French TECUMSEH compressor | ||||
| Heating Element | Nichrome heater | ||||
| Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
| Safety Device | over-temperature protection; over-current protection; Refrigerant high-pressure protection; Earth leakage protection | ||||
| Exterior Material | Steel Plate with protective coating | ||||
| Interior Material | SUS304 stainless steel | ||||
| Thermal Insulation | Polyurethane foam and insulation cotton | ||||
| Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
| Standard Configuration | 1 Cable hole with plug; 2 shelves | ||||
Product Operate Guide
To operate the temperature test chamber safely and effectively, start by confirming that the chamber is level and free from obstructions. Power on the system and allow the control interface to complete its initialization sequence. Program the desired temperature settings and ramp schedules using the touchscreen controller, and verify all parameters before initiating the test. Place samples in the chamber with sufficient spacing to allow unobstructed airflow and consistent thermal exposure. Monitor the temperature readouts periodically to ensure conditions remain stable throughout the testing process. Upon completion, carefully remove the samples and inspect the chamber for any residue or condensation. Routine checks of sensors, fans, and heating elements, along with proper sample handling, will help maintain optimal performance, prolong equipment life, and support safe operation.
Video of the Temperature Test Chamber
Comprehensive Warranty and Support
LIB provides robust warranty and after-sales support for all Temperature Test Chambers, ensuring long-term reliability and peace of mind. Each chamber comes with a standard 3-year warranty covering parts and workmanship, backed by lifetime technical support and maintenance guidance. Our team of trained specialists is available 24/7 to assist with troubleshooting, calibration advice, and operational guidance. In the rare event of a critical failure, LIB offers prompt repair services or a replacement unit to minimize downtime. With proactive service and responsive support, customers can focus on testing with confidence, knowing their chamber is protected and performance is guaranteed.
