A Southeast Asian manufacturing site required a robust environmental testing solution to support the reliability evaluation of large-scale motor assemblies. LIB Industry successfully installed a 98 m³ walk-in temperature and humidity chamber on the second floor of the customer's laboratory, creating a controlled environment capable of reproducing harsh climatic conditions ranging from 0 °C to +150 °C and 20%RH to 98%RH. The project focused on achieving smooth on-site integration, maintaining precise testing performance, and completing the installation within a demanding schedule.
Step 1: Site Assessment & Component Handling
Following two detailed site inspections, the installation area is fully prepared before the chamber delivery. With the assistance of lifting equipment such as mobile cranes and forklifts, a team of experienced technicians carefully transfers the chamber modules through the reserved access opening into the laboratory. After all components are positioned, the team removes the packaging, checks each part for potential shipping damage, and organizes panels, accessories, fasteners, and installation tools in designated areas to ensure an efficient assembly process.
Step 2: Chamber Frame Assembly & Alignment
Begin by installing the bottom platform and fine-tuning its position with laser leveling equipment to achieve a stable and accurate foundation. Next, assemble the front, rear, and side wall panels onto the base structure, ensuring each section is properly aligned and securely connected. After completing the wall installation, mount the top panel carefully and make necessary adjustments to guarantee a precise fit, smooth connections, and overall structural stability.
Step 3: Panel Fixing & Joint Sealing
Once the chamber panels are accurately positioned, fasten all connecting points to reinforce the overall structure. The specified panel joints are then welded to enhance mechanical strength and prevent air leakage. After welding, the seams are carefully polished and finished to create smooth, uniform connections, ensuring a durable, well-sealed, and airtight chamber enclosure.
Step 4: Installation of Core Systems & Electrical Connections
Install the refrigeration system, including the condensing unit and refrigerant piping, followed by the integration of the humidity generation system and water supply connections. After completing the mechanical setup, perform sensor installation and calibration to ensure accurate measurements. Finally, complete the electrical wiring of the control cabinet, connect all monitoring components, and verify reliable communication between the controller and sensors.
LIB Industry's full‑lifecycle approach to the 98 m³ walk‑in temperature and humidity chamber in Vietnam—from initial concept and rigorous site surveys through precision manufacturing, exhaustive factory testing, seamlessone‑stop installation, and formal handover—demonstrates our commitment to reliability at every step.
